- 160mm front travel
- 150mm dw-link rear travel
- 2.5” tire clearance
- Carbon fiber front and rear triangle
- Available in five sizes small (S), medium (M), extra medium (XM), large (L),
- and extra large (XL), fits riders between 5’2” and 6’7”
- Mixed wheels (MX) or 29” via flip chip
- Sizes S and M ship as MX, XM thru XL ship as 29”
- Frame weight of 7.6 lbs (3.5 kg) for a size XM with Fox Float X shock
WARRANTY
- Lifetime warranty on frames and wheels
- Lifetime replacement on bushings
Specifications:
DETAILS
- Slack 64.5˚ head angle
- Size specific seat angles (76.5˚-77.5˚)
- Actually, we did size specific everything
- 34.9mm seatpost
- Clearance for a really really long dropper
- 55mm chainline
- Threaded BB (73mm BSA)
- Coil shock compatible
- Metric 230x60 shock
- ISCG 05 compatible with removable adapter
- Internal tunnels for cable routing
- 22oz bottle on size small, 26oz on all other sizes
- Molded rubber swing arm protectors
- IGUS bushings in the lower link, bearings in the upper link
- 220mm max rotor size
- UDH rear hanger
- 148mm rear axle spacing
- Large Internal frame storage with easy access door
- Sustainably sourced internal frame bags designed in partnership with Cotopaxi
Build Kit:
| FORK | Fox Float 36, Factory Series, GripX, 160mm, 29”, 110mm x 15mm |
| SHOCK | Fox Float X, Factory Series, 2-Pos Adj. w/EVOL, 230mm x 60mm |
| RIMS (F/R) | Blackbird Send Alloy, 32 Hole, S-M, F: Send I 29” R: Send II 27.5” XM-XL, F: Send I 29” R: Send II 29” |
| HUBS (F/R) | Ibis Logo, 32H, 6-Bolt, F/R: Boost |
| SPOKES/NIPPLES | Sapim, Dlight Double Butted, 14g Alloy |
| FRONT TIRE | Maxxis DHF, 29”x 2.5”, Exo+ |
| REAR TIRE | S-M: Maxxis DHR2, 27.5” x 2.5”, Exo+ XM-XL: Maxxis DHR2, 29” x 2.5”, Exo+ |
| BRAKES | SRAM Code RSC, 4-Piston |
| ROTORS (F/R) | SRAM Centerline, F: 200mm, R: 180mm |
| CRANKSET | SRAM GX, Eagle Transmission, DUB, SM-MD: 165mm, XM-XL: 170mm |
| BOTTOM BRACKET | SRAM DUB BSA |
| REAR DERAILLEUR | SRAM GX, Eagle Transmission |
| SHIFTER | SRAM GX, Eagle Transmission |
| CASSETTE | SRAM GX, Eagle Transmission, 10-52T |
| CHAIN | SRAM GX, Eagle Transmission |
| HEADSET | Cane Creek 40: ZS44/ZS56 |
| GRIPS | Lizard Skin Charger Evo |
| HANDLEBAR | Blackbird HiFi, 35mm, 800mm |
| STEM | Blackbird, 35mm, S-M: 35mm, XM-XL: 50mm |
| SEATPOST | Bike Yoke Revive Dropper, 34.9mm, S: 125mm, M: 160mm, XM: 185mm, L-XL: 213mm |
| SADDLE | WTB Silverado, Fusion, 142mm |
| POWER | SRAM AXS Battery & Power Pack Charger |
| OPTIONAL UPGRADE | i9 Carbon Wheelset: +$1,400 |
